TL;DR
A hobbyist has developed a revised version of a voltmeter clock, featuring a cleaner design and continuous motion. The project involves custom-built enclosure, simple electronics, and careful calibration. This demonstrates accessible electronics DIY with practical aesthetic improvements.
A hobbyist has unveiled a redesigned voltmeter clock featuring a cleaner aesthetic and continuous motion, using off-the-shelf components and custom craftsmanship. This project highlights accessible DIY electronics and design improvements that appeal to electronics enthusiasts and makers.
The new voltmeter clock uses three generic 90° panel voltmeters from Amazon, disassembled and customized with printed decals for a precise look. The design includes a recessed front panel to hide the meters’ plastic flanges, achieved through CNC machining and careful assembly. The enclosure features a curved side wall, crafted by bending and gluing a shaped wooden panel, resulting in a seamless appearance.
The circuit employs an AVR128DB28 microcontroller powered by a standard wall wart, interfaced with the meters via digital output pins. It uses a simple pulse train to drive the meters, avoiding complex digital-to-analog converters. The system includes pushbuttons for manual time setting, and software controls the duty cycle of the pulses to achieve smooth, continuous motion of the clock hands.
Why It Matters
This project demonstrates that functional, aesthetically pleasing clocks can be built with affordable, readily available components and basic electronics skills. It offers a compelling example for hobbyists interested in combining electronics, craftsmanship, and customization. The clock’s continuous motion and refined appearance make it a notable DIY achievement in analog clock design.
